Customized spiral sand washing machine, fully enclosed oil bath transmission device, energy-saving high-capacity spiral sand washing machine, large-capacity spiral sand washing machine, long spiral

Customized spiral sand washing machine, fully enclosed oil bath transmission device, energy-saving high-capacity spiral sand washing machine, large-capacity spiral sand washing machine, long spiral

نام تجاری:	WeSeW
شماره مدل:	Kai001
مقدار تولیدی:	1 عدد
قیمت:	US$20,000~US$80,000 per pc
شرایط پرداخت:	T/T، وسترن یونیون
توانایی عرضه:	10000 عدد در ماه

جزئیات اطلاعات

توضیحات محصول

جزئیات اطلاعات

محل منبع:

چین

گواهی:

CE,UL

مواد:

فولاد ضد زنگ/سفارشی

ویژگی مواد:

مقاوم در برابر حرارت ، مقاوم در برابر آتش

برنامه:

صنایع شیمیایی ، حمل و نقل دانه ، حمل و نقل معدن ، نیروگاه

اجزای اصلی:

موتور

ابعاد (L*W*H):

سفارشی

مشخصات:

سفارشی

نام:

ماشین شستشوی شن

جزئیات بسته بندی:

کیس چوبی

قابلیت ارائه:

10000 عدد در ماه

برجسته کردن:

fully enclosed sand screw washer,energy-saving spiral sand washer,large-capacity oil bath sand washer

energy-saving spiral sand washer

large-capacity oil bath sand washer

توضیحات محصول

Customized Spiral Sand Washing Machine

High-performance spiral sand washing equipment featuring fully enclosed oil bath transmission, energy-efficient operation, and large processing capacity for industrial applications.

Professional OEM spiral sand washing equipment designed for processing river pebbles, limestone, and granite with washing capacities ranging from 40-300t/h.

Product Overview

The spiral sand washing machine represents our latest innovation in high-efficiency sand and gravel processing equipment. Engineered to work seamlessly with sand making machines, this system performs artificial or natural sand washing, grading, and impurity removal operations with exceptional precision.

Customized for industrial mineral processing, river silica sand washing, and construction applications including highway projects, hydropower plants, and gravel operations with minimal investment requirements.

Our integrated Spiral Sand Washing and Recycling Machine combines advanced sand washing, fine sand recovery, and dehydration technologies in a compact, efficient package that delivers clean final products with minimal fine sand loss, high throughput capacity, extended service life, and reduced maintenance costs.

Technical Specifications

Motor Type	AC Motor
Core Components	Motor
Place of Origin	China
Weight	30000 KG
Warranty	1 Year
Color	Custom
Video Inspection	Provided
Machinery Test Report	Provided
Dimensions (L×W×H)	According to model
Product Name	Spiral Sand Washing Machine
Keyword	Sand Washing Machine
Application	Sand washing, mineral classification
Feeding Particle Size	40mm

Key Features

High Cleaning Efficiency: Effectively removes dirt, clay, and organic impurities to improve sand quality
Large Processing Capacity: Handles from several tons to several hundred tons per hour depending on model
Low Power Consumption: Energy-efficient operation significantly reduces operating costs
Minimal Sand Loss: Advanced design preserves fine sand and reduces material waste
Durable Construction: Wear-resistant steel components ensure long service life with minimal maintenance
Eco-Friendly Operation: Incorporates water recycling systems and energy-efficient motors

Superior Cleaning Performance

External sealing structure with fully enclosed oil bath transmission device, combined with ingeniously designed spiral blades, ensures high-quality cleaning operations that meet requirements for high-grade materials.

Enhanced Washing Efficiency

Long spiral body with optimized screw device for slurry mixing provides high mechanization. Compared to wheel bucket sand washing machines, our system offers larger processing capacity with lower water content and mud content in the final sand product.

Precise Classification

Professionally designed material guide plate and adjustable long overflow weir plate, combined with optimized screw speed, enable effective washing of small particle size materials while ensuring accuracy in material classification.

Reliable Operation

Spiral blades manufactured from compressive, wear-resistant materials with transmission components separated from water and materials result in low failure rates, ensuring continuous equipment operation and reduced operational costs.
